환경: springboot3, spring batch5, mybatis
그동안 jpa만 주구장창 사용했어서 올만에 Mybatis 설정이다!
1. 디비 정보 등록(application.yml)
2. 빈 등록
@Configuration
@RequiredArgsConstructor
@MapperScan(
value = {"com.batch.ranking.mapper"},
annotationClass = LogDataSource.class,
sqlSessionFactoryRef = "LogDbSqlSessionFactory",
sqlSessionTemplateRef = "LogDbSqlSessionTemplate")
public class LogDataSourceConfig {
public static final String SOURCE_DATASOURCE_NAME = "LogDbDataSource";
@Value("classpath:mybatisConfig.xml")
private Resource configLocation;
@Bean(SOURCE_DATASOURCE_NAME)
public DataSource LogDbDataSource() {
DataSourceProperty dataSourceProperty = //get them from property
Properties properties = new Properties();
properties.setProperty("url", dataSourceProperty.getJdbcUrl());
properties.setProperty("user", dataSourceProperty.getUsername());
properties.setProperty("password", dataSourceProperty.getPassword());
AtomikosDataSourceBean dataSource = new AtomikosDataSourceBean();
dataSource.setUniqueResourceName(SOURCE_DATASOURCE_NAME);
dataSource.setXaDataSourceClassName("com.mysql.cj.jdbc.MysqlXADataSource");
dataSource.setXaProperties(properties);
dataSource.setMaxPoolSize(connectionPoolProperty.getMaximumPoolSize()); //from property
dataSource.setMinPoolSize(connectionPoolProperty.getMinimumIdle());
return dataSource;
}
//Qualifier is mandatory otherwise it will connect to Primary bean
@Bean
public SqlSessionFactory LogDbSqlSessionFactory(
@Qualifier("LogDbDataSource") DataSource LogDbDataSource) throws Exception {
SqlSessionFactoryBean bean = new SqlSessionFactoryBean();
bean.setConfigLocation(configLocation);
bean.setDataSource(LogDbDataSource);
return bean.getObject();
}
@Bean
public SqlSessionTemplate LogDbSqlSessionTemplate(
@Qualifier("LogDbSqlSessionFactory") SqlSessionFactory LogDbSqlSessionFactory) {
return new SqlSessionTemplate(LogDbSqlSessionFactory);
}
}2-1. mybatis 설정은 자바로 해도 되지만 분리하는 게 가독성이 좋아서 분리하였다.
<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE configuration PUBLIC "-//mybatis.org//DTD Config 3.0/EN"
"http://mybatis.org/dtd/mybatis-3-config.dtd">
<configuration>
<settings>
<setting name="mapUnderscoreToCamelCase" value="true"/>
</settings>
<typeAliases>
<typeAlias type="com.batch.adapter.mybatis.handlers.RankingTypeHandler" alias="RankingTypeHandler" />
</typeAliases>
</configuration>2-2. 매퍼 마킹하는 어노테이션
@Retention(RetentionPolicy.RUNTIME)
@Target({ElementType.TYPE})
public @interface LogDataSource {}3. 사용하는 job에서 부를 경우
private final SqlSessionFactory LogDbSqlSessionFactory;
@Bean
@StepScope
public MyBatisCursorItemReader<Ranking> DailyRankingReader() {
return new MyBatisCursorItemReaderBuilder<Ranking>()
.sqlSessionFactory(LogDbSqlSessionFactory)
.queryId(
"com.batch.domain.ranking.mapper.DailyRankMapper.selectDailyTop100")
.build();
}4. 매퍼에 쿼리 작성
@LogDataSource
public interface DailyRankMapper {
List<Ranking> selectDailyTop100();
}<!DOCTYPE mapper PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN" "http://mybatis.org/dtd/mybatis-3-mapper.dtd">
<mapper namespace="com.batch.domain.ranking.mapper.DailyRankMapper">
<resultMap id="sinyutnoriRanking"
type="com.batch.domain.ranking.model.Ranking">
<constructor>
<idArg column="memberid" javaType="java.lang.String" name="memberId"/>
<arg column="regdate" javaType="java.time.LocalDate" name="registerDate"/>
<arg column="kind" javaType="com.batch.domain.ranking.type.RankingType" name="RankingType" typeHandler="RankingTypeHandler"/>
<arg column="gamemoney" javaType="java.lang.Long" name="gameMoney"/>
<arg column="winrate" javaType="java.lang.Long" name="winRate"/>
<arg column="matchcnt" javaType="java.lang.Long" name="matchCount"/>
<arg column="wincnt" javaType="java.lang.Long" name="winCount"/>
<arg column="defeatcnt" javaType="java.lang.Long" name="defeatCount"/>
<arg column="ranking" javaType="java.lang.Integer" name="ranking"/>
</constructor>
</resultMap>
<select id="selectDailyTop100" resultMap="Ranking">
<![CDATA[
SELECT memberid
, regdate
, kind
, gamemoney
, winrate
, matchcnt
, wincnt
, defeatcnt
, @RNUM := @RNUM + 1 AS ranking
FROM Table
ORDER BY (wincnt + defeatcnt + drawcnt) DESC
, (wincnt / (wincnt + defeatcnt + drawcnt)) * 100 DESC
, gamemoney
) B, (SELECT @RNUM := 0) r
WHERE @RNUM < 100
]]>
</select>
</mapper>5. enum으로 바로 꺼내고 싶다면 type handler 작성
public class RankingTypeHandler extends BaseTypeHandler<RankingType> {
@Override
public void setNonNullParameter(
PreparedStatement ps, int i, RankingType parameter, JdbcType jdbcType)
throws SQLException {
ps.setInt(i, parameter.getCode());
}
@Override
public RankingType getNullableResult(ResultSet rs, String columnName)
throws SQLException {
return RankingType.findByCode(rs.getInt(columnName)).orElse(null);
}
@Override
public RankingType getNullableResult(ResultSet rs, int columnIndex)
throws SQLException {
return RankingType.findByCode(rs.getInt(columnIndex)).orElse(null);
}
@Override
public RankingType getNullableResult(CallableStatement cs, int columnIndex)
throws SQLException {
return RankingType.findByCode(cs.getInt(columnIndex)).orElse(null);
}
}
여기서 궁금한 사항
Mapper interface를 직접 사용하지 않은데도(자바 로직에서) 클래스가 필요한 것인가?
reader/writer를 보면 아래와 같이 직접 db factory를 연결했으니 interface는 필요 없는 게 아니냐는 문의를 주셔서 좀 더 알아본다.
@Bean
@StepScope
public MyBatisCursorItemReader<SinyutnoriRanking> dailyRankingMatchCntReader(
@Qualifier(HangameLogDataSourceConfig.SESSION_FACTORY) SqlSessionFactory logDb) {
return new MyBatisCursorItemReaderBuilder<SinyutnoriRanking>()
.sqlSessionFactory(logDb)
.queryId(LOG_MAPPER + "selectDailyTop1000UsersByMatchCnt")
.build();
}
설정이 대략 이런식으로 연결되어 있다고 할 때...
@Configuration
@RequiredArgsConstructor
@MapperScan(
value = {"com.batch.domain.mapper.gamemapper.*"},
annotationClass = DataSource.class, //mapper interface에 해당 어노테이션을 달아야
sqlSessionFactoryRef = DataSourceConfig.SESSION_FACTORY,
sqlSessionTemplateRef = "DbSqlSessionTemplate")
public class DataSourceConfig {@DataSource
public interface GameMapper {<mapper namespace="com.batch.domain.mapper.gamemapper.GameMapper">
1. interface 삭제 가능? No
: GameMapper삭제하고 (Config에 annotationClass 주석하니; 하건 안하건 둘 다) 에러 발생
Caused by: java.lang.IllegalArgumentException: Mapped Statements collection does not contain value for com.batch.domain.mapper.gamemapper.GameMapper.insertRankxml의 namespace가 인터페이스와 연결되어 있어야 쿼리 주입이 가능
2. 직접적인 함수의 호출이 없으므로 함수는 삭제 가능? Yes
xml안에는 <select>, <insert> 등 여러 쿼리가 있지만 직접 호출하지 않으므로 interface에 연결하는 함수는 없어도 된다.
@DataSource
public interface GameMapper {
// List<Ranking> selectDailyTop1000UsersByMatchCnt();
}@Bean
@StepScope
public MyBatisCursorItemReader<Ranking> dailyRankingMatchCntReader(
@Qualifier(DataSourceConfig.SESSION_FACTORY) SqlSessionFactory logDb) {
return new MyBatisCursorItemReaderBuilder<Ranking>()
.sqlSessionFactory(logDb)
.queryId(LOG_MAPPER + "selectDailyTop1000UsersByMatchCnt")
.build();
}select 함수가 직접적으로 선언되지 않아도 작동한다.
작동은 되지만 나중에 관리차원에서 헷갈릴까 봐 지울지 말지 약간 걱정은 된다..
